Lubricated vacuum unit BluVacD

industrial

BluVacD – Decentralized vacuum units for plant-side separators Designed for the parallel extraction of air and water from a plant-side separator (e.g. a vacuum tank) in the calibration table Energy-saving vacuum generation due to speed-controlled vacuum pump or speed-controlled side channel compressor Energy-saving water discharge due to speed-controlled discharge pump from the ME-...-BVD series Media Gases with water shares / water Dry and humidified gases / water Motor 1,5 – 5,5 kW (20 – 60 Hz), 3~Mot Material design Stainless steel Plastics Cast iron Copper alloy Suction connection VB: G 1 1/2 – 2 VG: G1 – DN 50 ME-125: G 1 Pressure connection VB: G 1 1/2 – 2 VG: G1 – DN 50 ME-125: G 3/4 Sealing Mechanical seal Dimensions (WHD) -/- Applications Further applications General controlled vacuum generation Plastics industry Vacuum calibration for the manufacturing of plastic profiles Production of polystyrene parts (EPP / EPS) Chemical industry Distillation / separation of liquids Recovery of condensates (solvents) Advantages Highly efficient by generating a demand-based vacuum Decentralised systems, smart control, easy handling As easy to install as existing vacuum pumps
