Water pump SM series
electricself-primingcentrifugal

water pump
water pump
water pump
Add to favorites
Compare this product


Characteristics

Fluid
water
Operation
electric
Priming
self-priming
Technology
centrifugal
Mobility
stationary, mobile
Domain
industrial, agriculture
Applications
irrigation, washing
Material
stainless steel, ceramic
Voltage
230 V
Other characteristics
suction, mechanical, multi-stage, flange, seal
Flow

80 l/min, 90 l/min
(21.13376 us gal/min, 23.77548 us gal/min)

Head

34 m, 58 m
(111'06" , 190'03" )

Power

0.7 kW, 1 kW
(0.95 hp, 1.36 hp)

Fluid temperature

Min.: 0 °C
(32 °F)

Max.: 40 °C
(104 °F)

Length

184 mm, 206 mm
(7 in, 8 in)

Width

343 mm
(13.5 in)

Height

200 mm, 212 mm
(7.87 in, 8.35 in)

Weight

8.3 kg, 11.9 kg
(18.3 lb, 26.24 lb)

Description

Centrifugal selfpriming multi-impeller water pumps able to develop high pressure and a high water lift with a comparatively low power consumption. Universal pump for civil and industrial purposes, for high pressure system and for irrigation in agriculture and sports fittings. LIMITS OF USE - Total suction lift up to 8 mt. - Continuous duty ENGINE - Two-Pole induction motor (n = 2850 min-1) - Insulation Class F - Protezione IP 44 MATERIALS - Pump body: Stainless Steel AISI 304 - Motor Support: Aluminium - Impeller: Noryl - Diffuser: Noryl - Pump flange: Stainless Steel AISI 304 - Shaft with rotor: Stainless Steel AISI 304 - Mechanical seal: Ceramic/Graphite/NBR
