Isolation transformer P1100SMDplanar
Add to favorites
Compare this product
Characteristics
- Type
- isolation
- Mounting
- SMD
- Other characteristics
- planar
- Electric power
Max.: 30,000 W
(40.7886 hp)Min.: 10,000 W
(13.5962 hp)
Description
Rated power 10kW-30kW / Frequency range 20-125kHZ
Topology - Full Bridge, Half Bridge, Full Bridge ZVS,
Push-Pull
Current rating max. 600A
Isolation voltage pri-sec/pri-core 5,000VDC
Soft switching, single or multiple outputs
Different switching frequencies, input/output voltages
Primary turns - other number (no fractions)
Secondary Ns1, Ns2 / Ns3 turns 1- 8 (no fractions)
Thermal solutions heat sinks, etc.
