Particle counter AvCount Lite

The AvCount Light for Skydrol has been specifically designed to measure the particulate of Skydrol hydraulic fluid. Skydrol is an advanced fire resistant aviation hydraulic fluid which inhibits corrosion and prevents erosion damage to servo valves. It has been approved by most airframe manufacturers including Airbus, Boeing and BAE Systems and has been used in their products for over 40 years. Due to the highly corrosive nature of Skydrol material this special version of the AvCount is fitted with Isolast seals and a protective inner case. With a simple test procedure and sub 4 minute test time, operator skill or expertise is kept to a minimum. AvCount Lite can hold up to 3 test methods with custom methods created on a PC before being uploaded. Test progress and results for up to 6 size bands are displayed as cumulative particles/ml and ISO 4406 cleanliness codes. Features • ISO 11171 calibration • Cumulative Particles/ml • ISO 4406 Cleanliness Codes • Portable, compact instrument • Online/offline (bottle sample) • Stand-alone or PC controlled • Programmable via PC • Integrated printer • Battery power optional Sample viscosity: The AvCount Lite can analyse samples with kinematic viscosities of up to 64 mm2/s. When used in conjunction with the optional Sample Delivery System, the viscosity range is extended up to 200 mm/s. Precision and accuracy: AvCount Lite is fitted with a precision dual piston pump. When measuring samples from a bottle, the pump draws an aliqot of sample through the measurement cell at a consistent flow rate. When connected to a pressurised line, the pump provides accurate metering and control.
