Differential pressure flow meter KFM 2100

volumefor liquidsfor compressed air

MALEMA KINETIC FLOW METER MODEL KFM 2100 KFM 2100 Series is an advanced flow element that is suitable for liquid, gas and steam flow measurement with high accuracy and repeatability. Thanks to its patented design where a stream lined bullet shaped flow element that causes a minimum disruption to the flowing medium providing unmatched flow turndown with very low pressure drop. KFM 2100 series is available as a flow element separately as well as a complete flow meter. In the first option, you have a choice of using a differential pressure transmitter of your preference. Alternatively, we can integrate the KFM flow element with a differential pressure transmitter and supply as a fully calibrated unit. FEATURES: - A novel design approach in fluid flow measurement - High turn down: 10:1 typical; up to 50:1 for some applications with multiple transmitters - No need for straight runs - Stream lined measuring section: Low pressure drop - No moving parts - Measurement is independent of flow regime: Suitable for laminar, turbulent and transition flow conditions - High accuracy and repeatability - Volumetric and mass flow measurement with built-in temperature sensor option - Suitable for liquids, gases and steam - Patented design (Patent No. US 7,478,565 B2) APPLICATIONS: · WATER AND WASTE WATER · CONDENSATE, COOLING WATER & HOT WATER · PETROLEUM PRODUCTS · ACIDS AND ALKALIES · COMPRESSED AIR · INDUSTRIAL GASES · STEAM
