Digital pH sensor UVCON-pH/ORP

pH SENSOR- SEPL make sensor we can directly use With various pH meters as a complete set • Plug in connection,convenient to install and replace the sensor • It can be installed with the thread PG13.5 • The outer tube material:Glass • The external dimension:12*120 mm DIGITAL pH SENSOR - • It can convert analog signals to digital signals. and it is a predictive digital pH sensor. • Data stored in the sensor interface such as zero point slope etc. • The measured value is stable and reliable. • Don't accept the influence of the surrounding environment such as temperature, electromagnetic field etc. • pH range: 0 to 14 • Temperature range:0 to 110℃ • The external dimension:12*120 mm pH/ORP TRANSMITTER SPECIFICATIONS- - - Functions - pH/ORP Measuring range: - -2.00pH to +16.00 pH - -2000mV to +2000mV Resolution : - 0.01pH - 1mV Accuracy: - ±0.01pH - ±1mV Temp. compensation : - Pt 1000/NTC10K Temp. range : - -10.0 to +130.0℃ Temp. compensation range : - -10.0 to +130.0℃ Temp. resolution : - 0.1℃ Temp. accuracy : - ±0.2℃ Ambient temperature range : - 0 to +70℃ Storage temp. : - -20 to +70℃ Input impedance : - >1012Ω Display : - Back light, dot matrix pH/ORP current output1 : - Isolated, 4 to 20mA output , max. load 500Ω Temp. current output 2 : - Isolated, 4 to 20mA output , max. load 500Ω Current output accuracy : - ±0.05 mA RS485 : - Mod bus RTU protocol Baud rate : - 9600/19200/38400 Maximum relay contacts capacity : - 5A/250VAC,5A/30VDC Data logging capacity - 500,000 Protection : - IP65 Power supply : - From 90 to 260 VAC, power consumption < 5 watts Installation : - panel/wall/pipe installation Weight : - 0.55Kg
