Duct fan YEVF Seriesaxialcoolingdrying
Add to favorites
Compare this product
Characteristics
- Type
- duct
- Configuration
- axial
- Function
- cooling, drying, ventilation
- Applications
- industrial
- Other characteristics
- direct-drive, low-pressure, flange
- Air flow
Max.: 120,000 m³/h
(4,237,760.007 ft³/h)Min.: 1,320 m³/h
(46,615.36 ft³/h)
Description
RANGE
V (m³/h) = 1320÷120000
Pt (kg/m²) = 4÷100
FEATURES
Low pressure axial ducted fans.
Light alloy die cast impeller with air foil profile blade.
Double flange drum duct (tight). Direct-coupled motor with impeller splined on the shaft.
TEMPERATURE
Temperature allowed:
Fluid temperature allowed in a range of -20°C and 60°C.
TYPICAL APPLICATIONS
This type of axial ducted fan is suitable to suck clean air.
Ventilation systems
Conditioning
Cooling processes
Fumes/gas elimination
driyng systems
Humidity regulation
Desiccation
