Spur gearbox C seriesconcentricsolid-shaft200 - 500 Nm
Add to favorites
Compare this product
Characteristics
- Type
- spur
- Shaft orientation
- concentric
- Shaft configuration
- solid-shaft
- Torque
- 200 - 500 Nm, 500 - 1000 Nm, 1 - 2 kNm, 2 - 5 kNm, > 10 kNm, 5 - 10 kNm
- Configuration
- compact
- Performance
- precision
- Applications
- for electric motors, transmission, industrial, shaft
- Other characteristics
- large
- Rotational speed
Max.: 4,000 rpm
(25,132.74 rad.min-1)Min.: 0 rpm
(0 rad.min-1)- Gear ratio
Max.: 119 unit
Min.: 29 unit
Description
High precision gearbox with large hollow bore
Overview
High capacity bearing directly integrated in the gearbox housing. Huge hollow bore for easy routing of cables.
Less than 1 arcmin Lost Motion
Fully sealed
Maintenance free for life
Large permissible bending moment on output
Motor connection with belt transmission or spur gear
Pre-stage provided on request
Advantages of Fine Cyclo C-Series
Low Hysteresis For Accurate Positioning
Compact Design
