Grinding honing machine SH-6000

horizontalCNCelectric

The SH-6000 is the result of a two-year development process with input from around the globe. All aspects of the CGM and KGM machines have been analyzed for improvement. The machine is engineered to improve operator productivity and increase reliability. MACHINE SPECIFICATIONS Stroke Length: 6 to 392 mm (.24 -15.43 in) FEATURES + BENEFITS Capable of honing to the tightest tolerances in the industry with consistent and accurate bore size control to .00025 mm (.000010 in) Utilizes diamond plated or metalbonded abrasive tooling for maximum performance Available is both high speed and high torque models Standard true running spindle with direct CGT tooling connection for quick changeover All electric foot pedal for setup and truing mandrels Coolant tank is 70 percent larger than earlier models - 208 L (55 gallon) Generous ergonomic work area Intuitive touchscreen is easy-to-use with a large 225 mm (9 in) display ADDITIONAL INFORMATION The next generation of high precision KROSSGRINDING® machines are suited for quick changeover for medium-to-high volume production with a higher level of control and new technology throughout.
