Cylindrical anti-vibration mount CM series
stainless steelgalvanised steelrubber

cylindrical anti-vibration mount
cylindrical anti-vibration mount
cylindrical anti-vibration mount
cylindrical anti-vibration mount
Add to favorites
Compare this product


Characteristics

Configuration
cylindrical
Material
stainless steel, galvanised steel, rubber
Applications
machine
Static load

Max.: 4,000 daN

Min.: 50 daN

Diameter

Max.: 200 mm
(7.874 in)

Min.: 80 mm
(3.15 in)

Description

Sunnex CM is an anti-vibration machine mount. This mount have a stabilizing and damping effect on your installations with reduction of emitted noise. Sunnex CM is designed without a retaining bolt to enable usage in narrow spaces. The depth and chamfer of the counterstrike is specially dimensioned to ensure that the external bolt or machines with built-in levelling bolts, is held in position. This functional design gives it a very low installation height and a long service life, which makes it cost effective and excellent for narrow spaces. Preferences •Loads up to 4000 kg, per machine mount •Galvanized or stainless Steel •Spécial Nitrite rubber mixture Applications •Engineering machinery •Warehouse equipment •Computer equipment •Scales Advantages •Excellent anti-vibration •Excellent friction to surface •Excellent for narrow spaces •Free standing
