Rotating cam limit switch SN2 Series SN2204/SN2107/SN2108/SN2114/SN2118
for elevatorminiatureIP67

Rotating cam limit switch - SN2 Series SN2204/SN2107/SN2108/SN2114/SN2118 - SUNS - for elevator / miniature / IP67
Rotating cam limit switch - SN2 Series SN2204/SN2107/SN2108/SN2114/SN2118 - SUNS - for elevator / miniature / IP67
Rotating cam limit switch - SN2 Series SN2204/SN2107/SN2108/SN2114/SN2118 - SUNS - for elevator / miniature / IP67 - image - 2
Rotating cam limit switch - SN2 Series SN2204/SN2107/SN2108/SN2114/SN2118 - SUNS - for elevator / miniature / IP67 - image - 3
Rotating cam limit switch - SN2 Series SN2204/SN2107/SN2108/SN2114/SN2118 - SUNS - for elevator / miniature / IP67 - image - 4
Rotating cam limit switch - SN2 Series SN2204/SN2107/SN2108/SN2114/SN2118 - SUNS - for elevator / miniature / IP67 - image - 5
Add to favorites
Compare this product


Characteristics

Technology
rotating cam
Applications
for elevator
Size
miniature
Protection level
IP67
Other characteristics
safety, with roller plunger, with return roller lever, waterproof

Description

Features: *Zinc die cast body *Earth grounding surface on same level as switching *Easily interchangeable contact block *Galvanically separated contacts *Screw terminals with self-lifting clamps for easy wiring *Positive Opening of NC contacts *4 x 90o actuator positions *Cable entry available: M20, PG13.5 and 1/2"NPT *Conform to EN 50047 standard Specifications: Operating Speed: 0.05mm-2m/sec Operating Frequency: Mechanical:120ops/min Electrical: 30ops/min Insulation Resistance: >100MΩ @ 500V DC Contact Resistance:  <25mΩ Rated Current/Voltage: 10A/600V AC (EN60947-5-1) Electrical Rating:  UL/cUL Listed(E216958) for AC15 A600/ DC13 Q300 Dielectric Strength: 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts Service Life:    Mechanically 10,000,000, Electrically 500,000 Operating Temperature: -25~80℃(-13~176°F) without formation of ice Humidity:     <95%RH Weight:    270~320g Degree of protection:  IP67

Catalogs

No catalogs are available for this product.

See all of SUNS‘s catalogs
