Storage server GPU ARS-221GL-NR

videoGPU2U

High Performance Computing, AI/Deep Learning Training, Large Language Model (LLM) Natural Language Processing, General purpose CPU workloads, including analytics, data science, simulation, HPC, application servers, andmore, Key Features Up to 960GB ECC LPDDR5X onboard memory option for minimum latency and maximum power efficiency; 5 PCIe 5.0 x16 FHFL Slots; 4 E1.S NVMe Storage Support; Form Factor Enclosure: 438.4 x 88 x 900mm (17.25" x 3.46" x 35.43") Package: (22.5" x 11" x 45.5") GPU Max GPU Count: Up to 2 double-width GPUs CPU-GPU Interconnect: PCIe 5.0 x16 CPU-to-GPU Interconnect GPU-GPU Interconnect: PCIe System Memory Slot Count: Onboard Memory Max Memory: Up to 960GB ECC LPDDR5X Drive Bays Configuration Default: Total 4 bays 4 front hot-swap E1.S NVMe drive bays M.2: 2 M.2 PCIe 5.0 x4 NVMe slots (M-key 22110) Expansion Slots Default 3 PCIe 5.0 x16 FHFL slots 2 PCIe 5.0 x16 FHFL double-width slots Network Connectivity: 1 RJ45 1GbE IPMI: Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Input / Output LAN: 1 RJ45 1 GbE Dedicated BMC LAN port(s) Video: 1 mini-DP port(s) TPM: 1 TPM Onboard/port 80 System Cooling Fans: 6 heavy duty fans with optimal fan speed control Power Supply 3x 2000W Redundant Titanium Level (96%) power supplies System BIOS BIOS Type: AMI 32MB SPI Flash EEPROM Management Redfish API; Supermicro Update Manager (SUM); KVM with dedicated LAN ; IPMI 2.0; Watch Dog; OOB Management Package (SFT-OOB-LIC ) PC Health Monitoring CPU: Monitors for CPU Cores, Chipset Voltages, Memory FAN: Fans with tachometer monitoring Status monitor for speed control
