Storage server AS -2145GH-TNMR-LCC

networkvideoGPU

Artificial Intelligence (AI), Large Language Model (LLM), Cloud Solution Provider (CSP), High Performance Comptue (HPC), Research Lab, Key Features Onboard 512GB HBM3 stacks memory; Optional PCIe configurations up to 6 PCIe x16 FHHL slots; Flexible networking options with 2 AIOM networking slots (OCP NIC 3.0 compatible); Default 8 hot-swap 2.5" NVMe dirve bays or Optional 8 hot-swap 2.5" SAS3/SATA3 drive bays via storage add-on card 2 Internal NVMe/SATA M.2 slots; 3 heavy duty fans w/ Liquid Cooled; 4x 2700W redundant Titanium level power supplies; Form Factor Enclosure: 438.4 x 88 x 848.7mm (17.3" x 3.5" x 33.4") Package: 672 x 250 x 1100mm (26.5" x 9.75" x 43.5") Processor Quad Socket SH5 GPU Max GPU Count: Up to 4 onboard GPUs Supported GPU: AMD: Instinct MI300A APU System Memory Slot Count: Onboard Memory Max Memory: Up to 512GB ECC HBM3 Drive Bays Configuration Default: Total 8 bays 8 front hot-swap 2.5" NVMe drive bays Option A: Total 8 bays 8 front hot-swap 2.5" SAS*/SATA* drive bays (*SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details) M.2: 2 M.2 NVMe slots (M-key) Expansion Slots Default 4 PCIe 5.0 x16 FHFL slots 1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible) 2 PCIe 5.0 x16 FHHL slots On-Board Devices Chipset: AMD SH5 Network Connectivity: Via AIOM Input / Output LAN: 1 RJ45 1 GbE Dedicated BMC LAN port(s) Video: 1 VGA port(s) 1 DisplayPort port(s) Serial: 1 COM port(s) (Rear)
