Physical Stats
Form Factor -
Proprietary WIO
Dimension -
8" x 13" (20.32cm x 33.02cm)
Core -
Up to 144 (E) cores
Memory Type -
6400 MT/s ECC DDR5 RDIMM Up to 128GB of memory with speeds of up to 6400 MT/s(1DPC)
DIMM Sizes -
32GB, 64GB, 128GB
Memory Voltage -
1.1V
Error Detection -
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset -
ASPEED AST2600 BMC
Network Controllers -
LAN -
Video Output -
1 VGA D-Sub Connector port(s)
Serial Port -
2 COM Port(s) (1 header; 1 rear)
TPM -
1 TPM Header
1 TPM TPM 2.0 onboard
Expansion Slots
PCIe -
1 PCIe 5.0 x8 Right Riser (in x16) slot,
1 PCIe 5.0 x32 Left Riser Slot,
4 PCIe 5.0 x8 PCIe5.0 MCIO connector
M.2 -
M.2 Interface: 2 PCIe 5.0 x2
Form Factor: 2280/22110
Key: M-Key
System BIOS
BIOS Type -
AMI 64MB AMI UEFI
BIOS Features -
ACPI 6.5
SMBIOS 3.7 or later
UEFI 2.9
PC Health Monitoring
Voltage -
VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chassis intrusion header, 6 -fan status, +5V standby, +5V, +3.3V, +12V, Memory Voltages
LED -
UID/Remote UID
CPU / System Overheat LED
Temperature -
Monitoring for CPU and chassis environment
CPU thermal trip support
Thermal Monitor 2 (TM2) support
PECI
FAN -
6x 4-pin fan headers (up to 6 fans)
Fan speed control
Overheat LED indication
Other Features -
WOL, UID, M.2 NGFF connector, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ACPI power management
