Physical Stats
Form Factor -
Proprietary
Dimension -
16.52" x 9.36" (41.96cm x 23.77cm)
Single Socket E2 (LGA-4710) supported, CPU TDP supports Up to 350W TDP
Core -
Up to 144 (E) cores
DIMM Sizes -
32GB, 64GB, 128GB
RDIMM: 32GB, 64GB, 128GB
Memory Voltage -
1.1V
Error Detection -
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset -
IPMI -
ASPEED AST2600 BMC
Network Controllers -
Dual LAN with Intel® Ethernet Controller E810-XXVAM2, Two (2) 25GbE Ethernet ports from KR interface to BP
Input / Output
TPM -
1 TPM Header
Expansion Slots
Form Factor: 2280/22110
System BIOS
BIOS Type -
AMI 64MB AMI UEFI
BIOS Features -
ACPI 6.5
SMBIOS 3.7 or later
UEFI 2.9
PC Health Monitoring
Voltage -
VBAT, System level control, Supports system management utility, Monitors CPU voltages, +5V standby, +5V, +3.3V, +12V, GPUtemperature
LED -
UID/Remote UID
CPU / System Overheat LED
Temperature -
Monitoring for CPU and chassis environment
CPU thermal trip support
Thermal Monitor 2 (TM2) support
PECI
FAN -
Fan speed control
Other Features -
UID
Control of power-on for recovery from AC power loss
ACPI power management
