Pico-ITX motherboard A4SAP-L
Intel® Processor N97Intel®DDR5 SO-DIMM

Pico-ITX motherboard - A4SAP-L - SUPERMICRO - Intel® Processor N97 / Intel® / DDR5 SO-DIMM
Pico-ITX motherboard - A4SAP-L - SUPERMICRO - Intel® Processor N97 / Intel® / DDR5 SO-DIMM
Add to favorites
Compare this product


Characteristics

Format
pico-ITX
Processor
Intel® Processor N97
Chipset
Intel®
Memory
DDR5 SO-DIMM
Extension slot
SATA3, M.2 Key E, M.2 Key B, Mini PCIe
Applications
industrial, network
Connectivity
LVDS, gigabit Ethernet, USB 2.0, USB 3.2, HDMI, RJ45, DisplayPort

Description

Physical Stats Dimension - 4" x 2.83" (10.16cm x 7.19cm) Core - Up to 4 cores / 6MB Cache System Memory 8GB, 16GB SODIMM: 8GB, 16GB Memory Voltage - 1.1V On-Board Devices Chipset - System on Chip SoC controller for 1 SATA3 (6 Gbps) ports Audio - ALC 888S HD Audio Network Controllers - N/A Input / Output LAN - Others - 1 8-bit GPIO header 1 HD Audio header (Mic-in/Headphone-out) (Note:Audio only support 0~60C) 1 SMbus and 5V/A SATA Power bo header 1 SMBus Expansion Slots System BIOS BIOS Type - 32MB AMI UEFI BIOS Features - ACPI 6.4 SMBIOS 3.3 UEFI 2.7 PCI FW3.0 RTC (Real Time Clock) Wakeup PC Health Monitoring Voltage - VBAT, System temperature, CPU temperature, 3.3V standby, +5V standby, +3.3V, +12V, Vcore, VDD2 (VDIMM) Temperature - CPU thermal trip support Other Features - WOL RoHS Control of power-on for recovery from AC power loss ACPI power management Operating Environment Operating Temperature Range - 0°C - 60°C (32°F - 140°F) Non-Operating Temperature Range - -40°C - 85°C (-40°F - 185°F) Operating Relative Humidity Range - 8% - 90% (non-condensing) Non Operating Relative Humidity Range - 10% - 95% (non-condensing)
