Physical Stats
Form Factor -
Proprietary
Dimension -
13" x 11.5" (33.02cm x 29.21cm)
Processor
Single Socket LGA-4844 (Socket sTR5) supported, CPU TDP supports Up to 350W TDP
Core -
Up to 96 cores, 192 threads
System Memory
Memory Capacity -
Memory Type -
16GB, 32GB, 64GB, 128GB, 256GB
RDIMM/3DS RDIMM: 16GB, 32GB, 64GB, 128GB, 256GB
Memory Voltage -
1.1.V
On-Board Devices
Chipset -
WRX90
Network Controllers -
N/A
TPM -
1 TPM Header
Expansion Slots
Form Factor: 2280/22110
System BIOS
BIOS Type -
AMI 32MB SPI Flash EEPROM
BIOS Features -
ACPI 6.5
SMBIOS 3.6 or later
UEFI 2.9
RTC (Real Time Clock) Wakeup
Management
Software -
Redfish API, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), KVM with dedicated LAN , IPMI 2.0
Power Configurations -
Power-on mode for AC power recovery, ACPI Power Management, S4/S5
PC Health Monitoring
Voltage -
System temperature, PCH temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +3.3V, +12V, CPU thermal trip support, Vmem, GPU temperature, Vcore, PWM fan speed control, 3x 4-pin fan headers
FAN -
7x 6-pin fan headers (up to 7 fans)
Fan speed control
Operating Environment
Operating Temperature Range -
0°C - 50°C (32°F - 122°F)
Non-Operating Temperature Range -
-20°C - 60°C (-4°F - 140°F)
Operating Relative Humidity Range -
10% - 85% (non-condensing)
Non Operating Relative Humidity Range -
10% - 95% (non-condensing)
