First performance hybrid architecture from Intel
4 independent display with 4K resolution
Fast AI hardware acceleration
Up to 96 EU with Intel® Iris® Xe graphics capable of 4K60 resolution
High speed connectivity through dual 2.5GbE
100% wide temp grade design and components applied
12-24V wide range power with RVP and TVS
Hailo-8™ powerful and efficient Edge AI solution integration ready
Physical Stats
Dimension -
5.7" x 4" (14.6cm x 10.16cm)
Processor
CPU -
Single Socket FCBGA-1744 supported, CPU TDP supports Up to 15W TDP
Core -
Up to 10 cores, 12 threads / 12MB Cache
System Memory
Memory Type -
DIMM Sizes -
8GB, 16GB, 32GB
Memory Voltage -
1.1V
On-Board Devices
Chipset -
System on Chip
Audio -
ALC 888S HD Audio
Graphics -
1 Intel® Iris® Xe Graphics port(s)
Network Controllers -
Dual LAN with Intel® Ethernet Controller I225-IT, 2.5G, TSN, industrial grade
Input / Output
Serial Port -
TPM -
1 TPM Chip
Others -
1 8-bit GPIO header
1 SMBus header
1 System Fan
Expansion Slots
Form Factor: 2230, 2242/2280
System BIOS
BIOS Type -
AMI UEFI
BIOS Features -
ACPI 6.4
SMBIOS 3.5 or later
UEFI 2.8
PCI FW 3.0
RTC (Real Time Clock) Wakeup
Management
System Management Software -
SuperDoctor® 5
Power Configurations -
ACPI Power Management, Wake-On-LAN, Force Power On by Jumper, Control of power-on for recovery from AC power loss, +12-24V DC Power Input
Security
Hardware -
Trusted Platform Module (TPM) 2.0
PC Health Monitoring
Voltage -
VBAT, +5V, +3.3V, +12V, +1.8V PCH, +3.3V standby, Vmem, Vcore, +1.05V
LED -
Power LED
LAN activity LED
HDD Activity LED
Temperature -
CPU thermal trip support
peripheral temperature
System temperature
CPU temperature
PCH temperature
