Physical Stats
Dimension -
12" x 10.1" (30.48cm x 25.65cm)
Processor
Single Socket SP5 supported, CPU TDP supports Up to 400W TDP
Core -
Up to 128 cores, 256 threads
System Memory
16GB, 24GB, 32GB, 40GB, 48GB, 64GB, 80GB, 96GB, 128GB, 192GB, 256GB
Memory Voltage -
1.1V
Error Detection -
Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset -
System on Chip
Network Controllers -
Dual LAN with Broadcom BCM5720 1GBase-T
Input / Output
Serial Port -
1 COM Port(s) (1 header)
TPM -
1 TPM Header
Others -
1 MCIO (PCIe 5.0 x8/SATA3) Port(s)
2 MCIO (PCIe 5.0 x8) Port(s)
Expansion Slots
Form Factor: 2280/22110
System BIOS
BIOS Type -
AMI 32MB SPI Flash EEPROM
BIOS Features -
ACPI 6.4
SMBIOS 3.5 or later
UEFI 2.8
Plug and Play (PnP)
USB Keyboard support
Management
Software -
Redfish API, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), KVM with dedicated LAN , IPMI 2.0
Security
Hardware -
Trusted Platform Module (TPM) 2.0
PC Health Monitoring
Voltage -
VBAT, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, VRM temperature, CPU thermal trip support, 1.8V standby
LED -
UID/Remote UID
BMC/IPMI Heartbeat LED
Other Features -
RoT
FAN -
6x 4-pin fan headers (up to 6 fans)
Operating Environment
Operating Temperature Range -
10°C - 35°C (50°F - 95°F)
Non-Operating Temperature Range -
-40°C - 70°C (-40°F - 158°F)
Operating Relative Humidity Range -
8% - 90% (non-condensing)
Non Operating Relative Humidity Range -
5% - 95% (non-condensing)
