Rack-mount chassis 513BTQC-350WB

1Ubackplane2 drive bays

2 x Full-height & Half-length expansion slot(s) Power Switch, UID Button & LED Indicators 4 x 40mm x28mm PWM fan(s) 1U 350W Multi-output Power Supply Platinum Level Processor Support Dual and Single Intel® and AMD processors Dimensions Height - 1.7" (43 mm) Width - 17.2" (437 mm) Depth - 15" (381 mm) Gross Weight - 14.5 lbs (6.58 kg) Packaging (W x H x L) - 19.5" (495 mm) x 6.9" (175 mm) x 22.4" (569 mm) Available Color - Black Expansion Slots 2x Full-height, Half-length expansion slot(s) (Riser Card Required) SAS or enterprise SATA HDD only recommended Backplane 2-Port 2U SAS3 12Gbps backplane, support up to 2x 2.5-inch SAS3/SATA3 HDD/SSD Front Panel Button - Power On/Off button Unit Identification (UID) button LED - Power status LED HDD activity LED System Information LED 2 Network Activity LEDs Port - 4x LAN Port(s) 1x VGA 4x USB Port(s) 1x IPMI 1x Com Port(s) Systems Cooling Fans - 4x 40x28mm PWM fan(s) Optional 2x 40x28mm PWM fan(s) Operating Environment (System) Operating Temperature Range - 5°C - 35°C (41°F - 95°F) Non-Operating Temperature Range - -40°C - 70°C (-40°F - 158°F) Operating Relative Humidity Range - 8% - 90% (non-condensing) Non Operating Relative Humidity Range - 5% - 95% (non-condensing) Power Supply 1U 350W Multi-output power supply Platinum level Power Efficiency - 93% Total Output Power and Input - 350W with Input 100 - 240Vac AC Input Frequency - 50-60Hz Dimensions (L x W x H) - 180 x 100 x 40 mm Output Type - 24pin ATX -12V - Max: 0.2A / Min: 0A +12V - Max: 29A / Min: 0.5A (100Vac - 240Vac) +5V - Max: 15A / Min: 0.2A +3.3V - Max: 12A / Min: 0.2A +5Vsb - Max: 3A / Min: 0A
