Triaxial accelerometer SV 151

MEMS

SV 151 triaxial accelerometer has very high shock resistance, no DC offset effect, very low power consumption and a frequency response down to DC level. For the SEAT transmissibility measurements the small size SV 151 is placed on the vehicle floor in accordance to ISO 2631-1. The sensor's built-in TEDS memory stores information about the accelerometer sensitivity that is automatically transferred to SV 106 instrument. SV 151 Whole-body Triaxial Accelerometer Specification Performance: Number of axis: 3 Sensitivity (± 5 %): 5.81 mV/ms-2 at 15.915 Hz Measurement range: 160 ms-2 PEAK Frequency response: 0 Hz ÷ 500 Hz Resonant frequency: 5.5 kHz (MEMS transducer) Electrical noise: < 0,066 ms-2 RMS, BL Wb weighting Electrical: Supply current: < 5.0 mA Supply voltage: 3.3 V ÷ 5.5 V Bias voltage: 1,5 V ± 0.1 V Output impedance: 51 Ohms Charge/discharge time constant30 sec. typ TEDS memoryinstalled (power supply pin) Environmental Conditions: Maximum vibration: 100 000 ms-2 shock survival for MEMS Temperature coefficient: <+/-0.02 %/°C Temperature: from -10°C to +50°C Humidity: up to 90 % RH, non-condensed
