Plug valve SCPelectricshut-offfor gas
Add to favorites
Compare this product
Characteristics
- Type
- plug
- Operation
- electric
- Function
- shut-off
- Media
- for gas
- Body
- stainless steel, cast steel, ETFE
- Applications
- flange, process, liquids, abrasive, for heavy loads, cylinder, shaft
- Associated function
- service
- Other characteristics
- ISO, DIN
- DN
Min.: 15 mm
(0.591 in)Max.: 100 mm
(3.937 in)- Pressure
Min.: 0 bar
(0 psi)Max.: 16 bar
(232.1 psi)- Temperature
Min.: -40 °C
(-40 °F)Max.: 200 °C
(392 °F)
Description
Fully lined process valves for shut-off or throttling of corrosive, abrasive liquid or gaseous media.
Main features
• Two-piece body made of cast steel, top entry
• Dynamic, maintenance-free shaft sealing acc. to TA-Luft
• Cavity-free design, low torque, full port
• One-piece cylinder/shaft, blow out proof, core of SS Duplex
• Rated breaking point outside of valve
• Cylinder options such as V-port, with pressure relief hole
• Easy maintenance at severe service conditions
• ISO top flange for direct mounting of pneum. quarter turn actuators
