CNC drilling and milling machine MAD3015D
rotating tablehorizontal6-axis

CNC drilling and milling machine - MAD3015D - SXKH GLOBAL - rotating table / horizontal / 6-axis
CNC drilling and milling machine - MAD3015D - SXKH GLOBAL - rotating table / horizontal / 6-axis
Add to favorites
Compare this product


Characteristics

Type
CNC
Structure
rotating table, horizontal
Number of axes
6-axis
Applications
deep hole
Number of spindles
2-spindle
Other characteristics
tapping
Power

68 W

Weight

45 t
(50 us ton)

Description

SXKH MAD Series are Horizontal Milling Machine with angular capacity & rotary table. The main advantage comes from its multi-task capacity to do big millings, drilling, tapping and deep hole drilling.This allows to accomplish all mold's milling and drilling needs in the six faces of the part with a convenient way. The combination of a wide angular capacity with a rotary table, allows extreme flexibility to reach all usual milling constrains areas. Model: MAD-3015D Diameter of the Hole for GunDrill Φ4-Φ35mm Diameter of the Hole for Ejector Φ18-Φ65mm Maximum Depth of the Hole for GunDrill 1500+500mm Maximum Depth of the Hole for ejector 1000mm Processing range (from Left to Right) of X3300mm Processing range of sliding table Y 1500mm Processing range of column Z 1200mm Spindle: Taper hole spindle BT40 Maximum speed of spindle 6000r/min(milling) 6000r/min(drilling) Efficiency: Fast speed (X,Y,W,Z) 10m/min Maximum speed of working table 2r/min Maximum speed of Ram 200°/min Power: spindle motor Milling 18.5kw, drilling 15kw X axis servo motor40N.m Y axis servo motor 40N.m W axis servo motor 22N.m Z axis servo motor 40N.m A axis servo motor 22N.m B axis servo motor 40N.w TOTAL POWER 68kw Cooling system: Pressure range of cooling liquid 2-11/1-1.7Mpa Flux of cooling liquid 6-80L/40-165Lmin CNC index table: 20 ton Measurement: 2200*1800mm Machine weight: 45 T CNC System: FANUCOi-MF
