Die sinking EDM ZNC540Ywire-cut
Add to favorites
Compare this product
Characteristics
- Type
- die sinking, wire-cut
- X travel
500 mm
(19.69 in)- Y travel
400 mm
(15.75 in)- Z travel
500 mm
(19.69 in)
Description
MODEL: ZNC540Y
Work Table Size(LxW): 800*500
Coordinate Axes Travel:
X axis: 500
Y axis: 400
Z axis: 250+250
Work Table Intemal Size(LxWxH): 1255*685*480
Max.electrode Weight: 100
Max Loading Of Worktable: 1000
Distance From Electrode
Plate To Work Table:
Max: 760
Min: 260
Z axis Two-direction positioning accuracy A:0.009/300mm
Z axis one-direction re-positioning accuracy R+ and R-:0.004/300mm
Z axis of the reverse difference (loss of momentum) B:0.006/300mm
Oil Tank Capacity: 550L
Machine Weight:1900KGS
External Dimension(LxWxH) 2070*1635*2450
