Die sinking EDM ZNC540

wire-cut

•15 inch LCD display; •High speed and high precision machining system; •Mirror processing special circuit; •Automatic protection circuit for carbon deposition prevention; •Multi functional hand control box input,simple display. MODEL: ZNC540 Work Table Size(LxW): 800*500 Coordinate Axes Travel: X axis: 500 Y axis: 400 Z axis: 250+250 Work Table Intemal Size(LxWxH): 12550*705*480 Max.electrode Weight:100 Max Loading Of Worktable: 1000 Distance From Electrode Plate To Work Table: Max: 760 Min: 260 Z axis Two-direction positioning accuracy A:0.008/300mm Z axis one-direction re-positioning accuracy R+ and R-:0.006 Z axis of the reverse difference (loss of momentum) B:0.008 Oil Tank Capacity: 650L Machine Weight:1900KGS External Dimension(LxWxH) 1600*1600*2030
