Die sinking EDM ZNC760

wire-cut

•15 inch LCD display; •High speed and high precision machining system; •Mirror processing special circuit; •Automatic protection circuit for carbon deposition prevention; •Multi functional hand control box input,simple display. MODEL: ZNC760 Work Table Size(LxW): 1200*700 Coordinate Axes Travel: X axis: 700 Y axis: 600 Z axis: 300+300 Work Table Intemal Size(LxWxH): 1940*1050*600 Max.electrode Weight:150 Max Loading Of Worktable: 2000 Distance From Electrode Plate To Work Table: Max: 1000 Min: 400 Z axis Two-direction positioning accuracy A:0.008/300mm Z axis one-direction re-positioning accuracy R+ and R-:0.006 Z axis of the reverse difference (loss of momentum) B:0.008 Oil Tank Capacity: 800L Machine Weight:3500KGS External Dimension(LxWxH) 2100*2000*2800
