Cone-bottom silo

unloadergalvanised steel

It is a type of discharge of the material within the silo. This movement of all the product at the same time causes great stresses on the walls of the silo that we calculate with the NF-P-22-630 standard. RAW MATERIAL: The company manufactures in galvanized corrugated steel, with a 600 gr/m² coating, ensuring a double service life more than other suppliers do. WIDE RANGE OF PRODUCTS: We offer this calculation for Flat Bottom silos, with capacities from 5 m³ to 25,000 m³ and for Hopper silos with different capacities, from 5 m³ to 2,649 m³ CALCULATION OF THE STRUCTURE: Silo calculation is made according to different norm as ANSI – ASAE EP 433 2033, EUROCODE EN-1991-4, or any different required norm. SILO COMPONENTS: Cylindrical body Made up of bodysheets and stiffeners, manufactured in structural steel S 350 GD Z600 hot dip galvanized. Access door Placed in the second ring to access to the interior of the silo. We provide two different sizes: 600x700mm, and 530x700mm. New door lock system with 3 pressure screws. Foam to improve silo tightness. Easy to assemble. Pre-installed door to avoiding extra works during erection.
