LCD module converter TBJ101LV-01

signalLVDS to LVDScompact

TBJ101LV-01 Scaler Board | Convert LVDS 60-pin / 40-pin to LVDS 20-pin | Support LCD resolution (max.): 1024×600, typical screen size: 7.0″/ 9.2″/ 10.1″ | Built-in backlight driver and VGL, VGH power supply circuit of the screen, a supplement to the LVDS signal of industrial motherboard | Structure in compact design leaves more space for the terminals | The TFT control board can be compatible with origin module EJ101NA-01G, CLAA101NC01C. The material is RoHS compliant. Function: TFT LCD Controller Supply Voltage (V): 5.0 Typ Interface: LVDS to LVDS LCM SIZE: Multiple LCM Resolution supported (pixel): 1024×600 PCB (W x H ) (mm): 60.0×54.0 Direct Current (without LCM ) (mA): 250 Typ LCM connector: 60PIN/0.5S LVDS connector: 20PIN/1.0S(DF14) Operational Temperature (°C): -20 ~ +70 Storage Temperature (°C): -30 ~ +80
