LCD module converter TBJ080VG-01

RGB to VGARGB to CVBSfor automatic controls

TBJ080VG-01 LCD Scaler Board | Convert RGB 50-pin to VGA, CVBS | Optional universal RGB dual 30-pin LCD module interface | Support LCD resolution (max.): 800×480, typical screen size: 7.0″/ 9.0″/ 10.1″ | Support button operation, multi-function on Screen Display (OSD) operation, and optional remote control function | The TFT control board can be compatible with our 7-inch TFT module TTX070QHE-01, 9-inch TFT module TTX090BHE-01, and origin AT070TN92, EJ080NA-05B, AT102TN03 V.9. The material is RoHS compliant. Function: TFT LCD Controller Supply Voltage (V): 12 Typ Interface: RGB 50-pin/Dual 30-pin to VGA/CVBS LCM SIZE（inch: Multiple LCM Resolution supported (pixel): 800×480 PCB (W x H ) (mm): 113.7×86.8 Direct Current (without LCM ) (mA): 230 Typ LCM connector: 50PIN-0.5S VGA connector: 12PIN-2.0S AV connector: 6PIN-2.0S Key connector: 8PIN-2.0S Operational Temperature (°C): -10 ~ +60 Storage Temperature (°C): -20 ~ +70
