4" display module TTH040BRT-02C
TFTIPScapacitive touch screen

4" display module - TTH040BRT-02C - TAILOR PIXELS TECHNOLOGY CO., LTD. - TFT / IPS / capacitive touch screen
4" display module - TTH040BRT-02C - TAILOR PIXELS TECHNOLOGY CO., LTD. - TFT / IPS / capacitive touch screen
4" display module - TTH040BRT-02C - TAILOR PIXELS TECHNOLOGY CO., LTD. - TFT / IPS / capacitive touch screen - image - 2
4" display module - TTH040BRT-02C - TAILOR PIXELS TECHNOLOGY CO., LTD. - TFT / IPS / capacitive touch screen - image - 3
Add to favorites
Compare this product


Characteristics

Screen type
TFT, IPS, capacitive touch screen
Format
720 x 720
Screen size
4"
Applications
industrial, for control panels, HMI
Interface
MIPI
Structure
round
Configuration/mounting
integrated
Width

123.5 mm
(4.8622 in)

Height

123.5 mm
(4.8622 in)

Description

TTH040BRT-02C | 4 inch Round Touch Display | High Resolution 720×720 | MIPI | I2C | The round display with a capacitive touch screen is designed especially for applicants requesting a unique interface on the control panel. This TFT display provides a full view, people can see the quality display image from any angle. This Liquid Crystal Display has a built-in JD9365DA controller. The material is RoHS-compliant. Diagonal (inch): 4.0″ Resolution (pixel): 720×720 Display Type: IPS Display Mode: Transmissive Optimal View: Full View Touch Screen: Capacitive Touch Screen Module Dimensions (mm) (W x H x D): 123.5×123.5×3.64 Active Area (mm) (W x H): 101.52×101.52 Luminance (cd/m2): 250 Interface: MIPI Driver IC: JD9365DA Operational Temperature (°C): -20 ~ +70 Storage Temperature (°C): -30 ~ +80
