A high resolution CCD system with software automatically senses the centre position of the dedicated CCD targets then calculates of displacement from a set datum to ensure a fast set up time with repeatable readings, as well as digitally outputting the result. This is particularly useful on large alignment projects such as aircraft jigs or large machine tools since a single operator can make measurements and adjustments along the construction or fixture while the target is displayed on the monitor.
•Clear digital output of X and Y minimises operator error
•Graphical output for reporting & storage of results
•Repeatability of measurement provided by CCD
•Rapid calculation of results for quick and easy assessment
•Ideal for automatic remote monitoring with data logging
•Typical accuracies: 5µm over 3m (decreasing with distance)
