Open paint booth

for partsactivated carbon filtercompact

The Paint Module Booth, designed by Technicis Filtration, offers a compact and modular solution for spray painting or coating small to medium-sized parts. The Paint Module is ideal for spray gun applications involving liquid products such as paint, varnish adhesives, and resins. Up to three filter levels can be intergrated into the unit to meet the specific application needs. A 1-meter depth extension helps channel airflow for optimal suction performance. Suction power complies with Carsat requirements, ensuring a regulatory airflow speed of 0.5m/s, wether for craftsmen or industrial use An ATEX Fan is available as an option for handling flammable products. It is possible to install an activated carbon filter to reduce odor and VOC emissions. Since 1992, Technicis Filtration has been a French manufacturer of filters and spray booths, specializing in air filtration for surface treatments and coatings. Features Heights/Widths L1,80m x H1,80m Raw Materials Exhaust unit with galvanized steel extension Centrifugal Fan : Double inlet Electric Motor Operating Specifications Motor Power: 1,1kw Power supply : 380v or 220v Air outlet ducting: 400mm diameter Air outlet on top of the unit Natural Air inlet : required in the room where the booth will be installed Performances Suction Flow rate : 6500m3/h Regulatory suction speed : 0,5m/s Other features Low Noise and Vibrition: High-performance double inlet fan Delivered in kit form (assembly available upon request) Manufactured in Nantes
