CNC punching machine TP Alpha Matic 15servo-electriclinear motor-drivenprofile
Add to favorites
Compare this product
Characteristics
- Control
- CNC
- Drive type
- servo-electric, linear motor-driven
- Product handled
- sheet metal, profile, for metal, metal strip, for cable ducts
- Associated function
- forming, punching, cutting, shearing, drilling, notching, embossing, marking, tapping, edge, engraving, machining, grooving, finishing, deburring
- Other characteristics
- auto-index, high-speed, multifunction, for fire extinguishers, rapid, micro-hole, turret, flexible, universal, free-standing, rotary, for the automotive industry, CE, with one rotating punching station, custom, horizontal, motorized, notching, single-punch
- Pressing force
250 N
- Engine power
4 kW
(5.44 hp)- Cadence
600 rad.min-1
(95.5 rpm)- X travel
1,250 mm
(49.21 in)- Y travel
1,500 mm
(59.06 in)- Plate thickness
Min.: 1 mm
(0 in)- Part weight
200 kg
(440.92 lb)- Tool change time
3 s
Description
It is suitable for own productions and for third party, with an excellent performance/investment ratio. The revolutionary vertical turret, exclusive of TecnoPunch technology, is equipped with 15 rotating stations that allow a considerable saving on tooling time and tool purchase costs.
• VERTICAL TURRET - UP TO 150 AUTO-INDEX TOOLS
The Vertical Turret stands out from any other automatic tool changing technology. Patented worldwide, its 15 stations are all equipped with auto-index technology that allows tool rotation from 0° to 360°.
The configuration of the Vertical Turret can be completely customized and thanks to the use of the Multi-tools it allows to have up to 50 auto-index tools.
• ALL AUTO-INDEX TOOLS
The TP Alpha Matic 15, through the advanced integrated auto-index system, allows you to orient any tool from 0° to 360° (auto-index), with a precision of 0.01°. Auto-index technology is also available for Multi-tool systems.
• ELECTRIC - 0 HYDRAULIC OIL
It is equipped with an advanced servo drive punching unit without any hydraulic oil, thus ensuring low energy consumption.
• TRUMPF AND TECHNOLOGY TOOLS
TECHNOLOGY punching machines have always been equipped with the best punching tools. TP Alpha Matic 15 can be equipped with TRUMPF style tools but is totally compatible with TECHNOLOGY style tools.
• FANUC CNC
TP Alpha Matic 15 is equipped with components provided by the world leader FANUC (CNC, motors and drives).
FANUC guarantees the availability of spare parts for 25 years and offers assistance in 108 countries.
