CNC punching machine TLX 34Hhydraulicfor metal sheetscutting
Add to favorites
Compare this product
Characteristics
- Control
- CNC
- Drive type
- hydraulic
- Product handled
- for metal sheets
- Associated function
- punching, cutting, forming, drilling
- Other characteristics
- auto-index, turret
- Pressing force
300 kN
- X travel
2,500 mm
(98.43 in)- Y travel
1,500 mm
(59.06 in)- Plate thickness
Min.: 1 mm
(0.04 in)Max.: 6 mm
(0.24 in)6 mm
(0.24 in)
Description
The True Turret Punch Press
The TLX 34H turret is equipped with a high turret tool change system, with a loading capacity of up to 34 tools, including 2 stations with rotation from 0° to 360° degrees (auto-index).
The turret of the TLX 34H is one of the highest on the market. This ensures the best quality in machining and maximum tool durability, thanks to the ability to guide the punch with greater stability.
CNC FANUC
The TLX 34E is equipped with components (CNC, motors, drives, and console) from the world leader FANUC, ensuring unique CNC reliability. FANUC guarantees spare parts availability for 25 years and support in 108 countries thanks to its extensive branch network.
Catalogs
Turret Line Punching Machine
32 Pages
