Data acquisition software

managementproduction planningmonitoring

Customized and modular solutions for the management and traceability of raw materials. SCADA SUPERVISORY CONTROL AND DATA ACQUISITION TDT Our SCADA TDT offers complete Batch Management for both raw materials (recipes, lot numbers) and products. Displaying a comprehensive visualization of Work In Progress, the software seamlessly integrates into existing or future information systems such as an ERP. MES functionality and extra modules can also be added if required. CF CROSS FORMULATION CF Cross formulation makes it possible to process complex recipes, including mixing times, tool speed and any intermediate level embedding, with mixer settings incorporated into the dosing recipe. PLC and Fieldbus communicate through data exchange, under the supervision of the operator. Each PLC (dosing and mixing) can operate independently from the other for greater safety while mixing data such as cycle time and temperature at the end of mixing are stored in the PC database. PM PREMIX MANAGEMENT Pre-mixes can be managed as separate recipes or as part of the main recipe. They can be manufactured in advance while retaining complete control of the total amounts required based on production planning. WM WAREHOUSE MANAGEMENT WM is primarily aimed at managing warehouses, processing all relevant postings as well as transactions such as goods received, goods issued and general stock transfers.
