Analysis software LMK Sticking Image

for displays

The LMK Sticking image package (SI-AddOn) allows analysis of the display burn in behavior according to the Sticking image standard of the work group of the automotive manufacturers in the DFF. For the image for burning in the test display the three level burn in pattern according to Dr. is Lauer used. After running the test display for 60min with the burn in image, this is replaced by a uniform gray value image (relaxation image). Using the SI-AddOn, the time behavior of the fading-out of the burn-in image can be evaluated by a time-controlled measurement series with the LMK. Here, Labsoft offers the possibility to control the display to be evaluated, thus automating the process from burning in to SI evaluation.
