Mechanical manipulator SPARK

with gripping toolCartesian

The SPARK, PIRANHA and PELIKAN model manipulators have been designed mainly to extract sprues from the mould: using these manipulators means the sprues from the pieces can be automatically separated and the material instantly recycled. Guarantee is also given that the sprue will not remain inside the mould, running the risk of damaging it. Suction pads can also be used in the case of the PIRANHA and PELIKAN models to extract the pieces. The rapid movement speed into the mould means the time the mould is open, especially with models fitted with servomotors (PIRANHA and PELIKAN), is limited. SPARK All pneumatic movements to keep costs low. The vacuum kit is optional and cannot be used at the same time as the gripper for the sprue. Rotation of the gripper is optional. The (6) programs are fixed. The sprue is released outside of the injection moulding machine gates. PIRANHA All movements are made via brushless servomotors. The vacuum kit is standard fit and can be used at the same time as the gripper for the sprue. Rotation of the gripper is standard fit. Programming is free. The sprue is released outside of the injection moulding machine gates. PELIKAN All movements are made via brushless servomotors. It is best suited to small sized presses. The vacuum kit is standard fit and can be used at the same time as the gripper for the sprue. Rotation of the gripper is standard fit. Programming is free. Possibility of telescopic vertical axis as an optional. The sprue can be released inside the press gates, for example, in a granulator located within the gates.
