Enclosed DC/DC converter 12 - 24 V, 36 - 240 W step-downregulatorinsulated
Add to favorites
Compare this product
Characteristics
- Configuration
- enclosed
- Electrical characteristics
- step-down, regulator
- Other characteristics
- insulated
- Input voltage
Max.: 24 V
Min.: 12 V
- Output voltage
Max.: 24 V
Min.: 12 V
- Power
Max.: 240 W
(0.33 hp)Min.: 36 W
(0.05 hp)
Description
High frequency low voltage stabilizers, for a stabilized direct current of 12VDC or 24VDC. Isolated from earth.
A large selection of entry voltages:
- 12V models: 8.5 to 16.0 VDC
- 24v models: 17.0 to 32.0 VDC
Exit voltages:
- 12v models: 13.6 VDC +/-15%
- 24v models: 27.2 VDC +/- 15%
Wide range : between 3 and 10 Amps
Working temperature: -25°C to +30°C (decreasing amps in a linear manner from +30°C to +80°C)
Connections: 4 flat connectible terminals, 6.3mm
Fixings: clip-able onto a T frame, fixed by screws at 3 points.
IHM: voltage presence indicated by red LED.
Electrostatic protections complying with ISO10605, ISO14892 standards.
Robust and sealed Box: anodized aluminium, IP 53
