Camera housing SON01X16C_Fflangecylindricalstainless steel
Add to favorites
Compare this product
Characteristics
- Construction
- flange
- Configuration
- cylindrical
- Material
- stainless steel
- Application
- for cameras
- Protection level
- high-temperature
- Depth
1,200 mm
(47.24 in)
Description
Housing SONDATEC 2.0 for cameras CAM12X1DD series, designed for continuous operation with high temperatures up to 2200°C, water and air cooled. Angle of sonda inclination 120°, it allows to use lens up to 85° diagonal angle of view. Field of vision: RIGHT. Made by Stainless Steel AISI316L (on request available version in AISI310S). Diameter 89 mm (Version 2.0), length 1200 mm. Connections for air and water placed on the top, straight type. Water fitting 1/2” M-BSPP, 60° flared. Air 3/8” M-BSPP. Version complete with welded flange.
Other TELEA TECNOVISION SRL products
Vision system up to 2200°C / SONDATEC
