Industrial inspection machine

non-contactautomatic

The PRO Series ​Case system is designed for non-contact, non-destructive, 100% automatic container inspection through a sealed cardboard and/or shrink wrapped case. The system offers the option of acoustic or proximity technology to inspect glass jars with metal closures or metal cans for pressure or vacuum after the containers have been sealed in the case. In many applications, the Case system will detect defects other than low pressure or vacuum. Some examples are missing containers, containers with missing lids or broken bottles, flat sours and damaged cans. Case System • ​​​​​​​​​100% non-contact inspection • Graphic screen shows defects in case • Acoustic and Proximity sensor heads (up to 6 heads) • Quick set sensor bridge for easy product changeover • Speeds up to 250 cases per minute​ Specifications ELECTRONICS ENCLOSURE : Power Requirements: 100-240 VAC, 50-60 Hz, 1-phase, 275 Watts Material / Raiting: Enclosure: 304 Stainless steel, NEMA 4X, IP65 Mounting: Bracket mount to conveyor side rail Operating Conditions: Stable ambient temperature: 0° - 50° C (32° - 122° F) Relative humidity: 0-90%, non-condensing Altitude: Sea level to 3,035 m (10,000 feet) CONVEYOR : Power Requirements: 110-125 VAC, 60Hz, 1-phase, 1500 Watts (or) 220 VAC to 240 VAC 50 Hz, 1-phase, 1500 Watts Inspection Speed: Maximum belt speed: 91.4 m/min (300 ft/min) Bridge Materials: ABS plastic, hard coat anodized aluminum Bridge Specification: Maximum case height: 260 mm (10.25 in.) Maximum case width: 406 mm (16.0 in.) Minimum container diameter: 45 mm (1.8 in.)​
