Power transformer ACEisolationdistributionelectrical power supply
Add to favorites
Compare this product
Characteristics
- Type
- power, isolation, distribution, electrical power supply
- Configuration
- dry
- Applications
- industrial, for electrical networks, for indoor service, for outdoor service, substation, for railway applications, for photovoltaic applications, for industrial use
- Electrical characteristics
- single-phase, voltage, medium-voltage
- Mounting
- floor-standing, pole-mounted, plug-in, in-line, wall-mount, surface-mount, pole-mounted
- Norms
- IEC
- Other characteristics
- control, primary, protection, safety, integrated, dry type epoxy resin, containerized, switching, flameproof, secondary, compact, AC, epoxy resin, vacuum impregnation, frequency, with copper windings, hermetically-sealed, auxiliary, test
- Electric power
Max.: 400 W
Min.: 200 W
- Output power kVA
Max.: 0.4 kVA
(0.543848 hp)Min.: 0.2 kVA
(0.271924 hp)- Primary voltage
Max.: 24 V
Min.: 10 V
- Secondary voltage
100 V
- Frequency
Max.: 60 Hz
Min.: 50 Hz
Description
General Characteristics
• Dimensions according to CEI-UNEL 21009 std
• Manufactured and tested acc. to IEC 61869-1/2
• Rated Insulation level up to 36 kV
• Frequency 50 or 60 Hz
• Rated primary current (Ipr)
Single primary current from 5 to 3000 A
Double primary current
Up to 2 x 300 A change on prim. winding
Up to 2 x 1500 A change on sec. winding
• Rated secondary current (Isr) 5 A
• Short-time current (Ith) up to 40 kA x 1s
• Rated dynamic current (Idyn) 2.5 x Ith
• Number of secondary 1 or 2
• Security factor ≤ 5 or ≤ 10
• Outdoor installation
• Accuracy class for measure: 0,5 - 0,5s - 0,2 - 0,2s
• Accuracy class for protection: 5P10 - 5P20 - 5P30
• Rated dynamic current (Idyn) 2.5 x Ith
• Weight 45-50
On request
• Third secondary
• Rated secondary current 1A • Sealable terminal cover
• Capacitive tap
