Isolation transformer TRD

encapsulatedindustrialfor medical applications

Internal isolation transformer at input, Full controlled conventional rectifier, Smart control and high reliability with DSP (Digital Signal Processor)... GENERAL SPECIFICATIONS Internal isolation transformer at input Full controlled conventional rectifier Smart control and high reliability with DSP (Digital Signal Processor) Float charge, equalizing charge and boost charge modes Automatic and manual charge modes Low output voltage ripple and high reliability 2x16 character LCD display, showing measurements, status and alarm messages Soſt start Led displays for easy observation of rectifier status Audible alarm Programmable current limitation Operation as voltage source or current source Calibration of measurements from front panel Language selection from front panel (English / German / Turkish / Dutch / Portuguese) DC Low / High, Line Failure, Over Temperature, Short Circuit protections Ability to program all operation parameters (Password protected) Programmable alarm relay contact outputs (4 standart, up to 16 relays as option) Possibility of monitor and control over RS232-RS485 Modbus communication Log records with date and time stamp up to 200 events. 24V / 48V / 110V / 125V / 220V output options OPTIONS Battery temperature compensation Ability to monitor batteries and battery low alarm, even when the AC input fails Active parallel (current sharing) operation up to 4 devices Easy observation via analog gauges Battery test with adjustable voltage and duration Transducers for input / output voltage(s) / current(s) (4-20mA and 0-10V) 12 pulse option to limit input current distortion Earth leakage monitoring Input Power / kVA / kW measurement
