On-line uninterruptible power supply TEOS+ 200RT

parallelthree-phaseAC

TEOS+ 200RT Online UPS is a DSP controlled uninterruptible power supply designed as 3-level with true double conversion technology. It stands out with its high output power factor (PF:1) and input power factor correction, high charging current power and maximum efficiency design. It is especially suitable for use in home-office applications and data centers. It offers flexibility of use with its prominent features such as frequency converter mode, wide voltage/frequency range, rack and tower usage option and multiple communication options. GENERAL SPECIFICATIONS Advanced DSP and 3-Level technology Output power factor 1.0 Active power factor correction (APFC), input power factor up to 0.99 High efficiency 95% (up to 98% in ECO mode) Advanced digital parallel technology 3:1 to 1:1 model settable Wide input voltage range (190 - 478 Vac) and frequency range (40 - 70Hz) 50 / 60 Hz frequency auto sensing Two modes of frequency conversion: 50Hz input / 60Hz output or 60Hz input / 50Hz output Dual-input design, supporting independent bypass Hot-swappable battery (10kVA) Flexible battery configuration (settable 16 - 20 pcs batteries) Digitally controlled charger High charging current available (Max. 10 A) Charging voltage and current configured by demands Linear debating in low voltage input reducing battery discharging times, extending the service life of battery Intelligent battery management, automatic floating / equalizing charge control, charger dormancy control, increasing battery life by 50% Ability to switch on the UPS with batteries Settable delayed start time when mains power is restored, reducing the impact on power grid or generator
