Bluetooth diagnostic pass thru Navigator TXB ZERO

for automobiles

A diagnostic interface dedicated to the diagnosis on outboard engines and personal watercrafts. Its design aims at ensuring compatibility with a wide range of engines, offering a versatile and flexible solution for the repair and maintenance needs of specialised technicians. Lastly, it integrates an advanced technology that allows recording the diagnostic tests also while moving*. A custom-developed diagnostic software TXB ZERO is supplied in a handy case that contains the necessary cables to operate on the many outboard motors and jet skis present in the IDC5 MARINE diagnostic software, specially developed for this tool and rich in technical data, interactive electrical diagrams, technical sheets, nominal values associated with errors, and much more. MANUFACTURER TEXA S.p.A. PROCESSOR ARM Cortex M4 (STM32F439ZIY6) MEMORY • SDRAM: 8 MB • Flash NAND: 4 GB VEHICLE BATTERY 12Vdc and 24Vdc system management EXTERNAL POWER SUPPLY 12 / 24 Vdc OPERATIONAL BAND 2400 – 2483.5 MHz MAXIMUM RADIO FREQUENCY POWER TRANSMITTED 4 dBm DIAGNOSTIC CONNECTOR OBD ISO15031-03 for 24 V systems SUPPORTED AUTOMOTIVE BUS TYPES • 4 HS CAN transceivers connected to OBD pins 3-11, 1-9, 12-13, 6-14 that can be enabled individually • 1 J1708 transceiver connected to pins 12-13 • 1 ISO9141-2, ISO14230 transceiver with 60mA current protection connected to pins 3 or 7 VISIBLE WARNINGS • Green/red bi-colour LED x1 • Blue LED x1 12 V CONSUMPTION < 120 mA 24 V CONSUMPTION < 60 mA OPERATING TEMPERATURE 0 ÷ 50 °C STORAGE TEMPERATURE – 20 ÷ 60 °C OPERATING MOISTUREESERCIZIO 10% ÷ 80% without condensation WEIGHT 15 g
