Wireless valve actuator SAB+

electricrotarywith servo-motor

Self-powered wireless EasySens® valve actuator for individual room temperature control. The new electronic heating valve actuator uses the temperature difference between the radiator and ambient room temperature to generate electrical energy by means of a thermo-electric generator. Sufficient energy can be stored in the integrated high-performance capacitor to ensure reliable operation even during periods of insufficient energy management (summer months, transition period between seasons). Adapters are available for numerous valve manufacturers. • Application/type : Actuator • Purpose : Room Climate Control • Measured values : temperature • Interface : EnOcean (868 MHz) • Functions : heating actuator operation, self-control mode, automatic closing point control, frost protection • Configuration : airConfig • Sensor : integrated digital temperature transmitter • Radio technology : EnOcean (IEC 14543-3-10) 868 MHz, transmission power <10 mW, EEP A5-20-01 (4BS) • Data transmission : bidirectional, measuring and transmission interval: every 2..20 minutes, optionally configurable, internal antenna • Operating range humidity : max. 85% rH non-condensing • Power supply : maintenance-free thermal energy harvesting, maintenance-free LiPo-battery • Display : LED for status feedback, red • Enclosure : PC • Colour : pure white, aluminium • Protection (IP) : IP40, according to EN 60529 • Connection : USB micro (power supply) • Mounting : screw mounting M30x1,5 • Packaging : case packaging • Device length (mm) : 63 • Device width (mm) : 60 • Device height (mm) : 85
