Absolute pressure transmitter DLF series

membrane4-20 mA0-10 V

Pressure transmitter for measuring absolute pressure of liquids, air or non-aggressive gases. Designed for use in refrigeration, hydraulics, production plants and processes. The dense stainless steel membrane makes the sensor suitable for use with refrigerants as well. For a quick & easy connection, a 5 m cable with a pre-installed connector is available (see 'Accessories'). The DLF can be optionally equipped with a 4-digit LED display. • Application/type : Pressure transducer • Purpose : Measure values • Measured values : pressure • Interface : Active, 0..10 V, 4..20 mA • Output voltage : 0..10 V, min. load 5 kΩ • Output current : 4..20 mA, max. load 500 Ω • Operating range temperature enclosure (°C) : -40..+105 • Operating range pressure : fluids, air or other non-flammable/non-aggressive gases • Measuring range pressure : -1..0 bar, 0..1 bar, 0..1,6 bar, 0..2 bar, 0..2,5 bar, 0..4 bar, 0..6 bar, 0..10 bar, 0..16 bar, 0..25 bar, 0..40 bar, 0..60 bar, 0..100 bar • Accuracy pressure : ±0,5% (typ. at 21 °C) • Power supply : 15..24 V = (±10%) SELV, 24 V ~ (±10%) SELV • Power consumption : typ. 0,15 W (24 V =), typ. 0,5 W (24 V =), 0,3 VA (24 V ~) • Material in touch with media : stainless steel V2A (1.4305), G1/2", G1/4" • Protection (IP) : IP65, according to EN 60529 • Connection : cable gland for wires with Ø=8 mm max., plug MVS according to DIN 175301-803 • Packaging length (mm) : 170 • Packaging width (mm) : 120 • Device length (mm) : 50 • Device width (mm) : 35 • Weight (g) : 60
