Valve pressurization skid SKA-100/S

for test bencheswith programmable logic controller (PLC)

Controlled by electronic PLC and configured by LCD touch screen monitor, this hydraulic/pneumatic pressurization skid could store test data, set-points, times and leak limits . The pressure set-point is automatically reached, leak is measured by electric bubbles counter and vacuum pump can ensure absence of air in the valve’s body. The wet test items are made of stainless steel and is dimensioned to take pressure up to 700 bar. High reliability is assured by metal to metal needle and it has a high filling flow ability. The reports of test can be obtained without external PC by 24cln thermal printer. H2O : 700 / 1050 / 1380 / 1600 bar AIR : - (SHV model : 0.998 / 0 bar) FILLING FLOW : 70 L/min (from external line) PRESSURIZATION POWER : 0,4 / 1,5 HP VACUUM PUMP OPT. : 36 m3 /h BACKSEAT TEST : Not available SEAT OVER PRESSURE TEST : Not available OPERATION HP TEST : Not available DBB TEST OPT. : Not available GAS TEST OPT. : Not available GAS BOOSTER OPT. : Not available CAVITY TEST OPT : Not available MULTISTATION OPT. : Not available ACTUATOR CONTROL PANEL OPT. : Not available ATEX CERTIFICATION OPT. : Not available FLUID ALLOWED : Water, Water & oil mixture, Glicole, Ethanol (Atex), Methanol (Atex).
