Pneumatic calibration pump 7118

manualfor pressure generation

Pocket sized pumps that provide a simple and compact solution to field pressure generation. Each pump combines a smooth and controlled operation with a rugged yet lightweight design, making them the ideal tool for instrumentation engineers that perform site pressure testing. Construction is anodized aluminium with a durable plastic handle that prevents body heat transfer from interfering with readings. An oversized check valve enables smooth operation, and dual o-rings on all pistons to ensure zero leakage. Both units are supplied with a 1 meter 6/4 mm hose and fitting (1/4 BSP as standard, others upon request). Optional digital pressure gauges are available with vacuum and compound models available. Recommended gauges are the TEG-CV7b models that cover the range of the 7118 and 7117 (vacuum to 7 bar) with accuracies of 0.2, 0.1, 0.05, and 0.02 % of full scale available. Features • 7118: Pneumatic 0 to 7 bar (100 psi) • 7117: Vacuum 0 to 950 mbar (28 inHg) • Non-oil based lubricant on moving parts • Dual o-rings on pistons ensure no leakage • Compact pocket sized pumps • H 220 x W 40 mm, 0.70 kg • Digital pressure gauges available
