Diesel generator set GG9500E3
single-phase50 Hzair-cooled

Diesel generator set - GG9500E3 - TMG POWER - single-phase / 50 Hz / air-cooled

Diesel generator set - GG9500E3 - TMG POWER - single-phase / 50 Hz / air-cooled - image - 2

Add to favorites

Compare this product

Characteristics

Motor type: diesel
Phase: single-phase
Frequency: 50 Hz
Cooling system: air-cooled
Power in kVA: 8.6 kVA, 9.5 kVA
(11.69 hp, 12.92 hp)
Voltage: 380 V
Length: 70 cm
(28 in)
Width: 59 cm
(23 in)
Height: 56 cm
(22 in)
Weight: 98 kg
(216.05 lb)

Description

Continuous Power The maximum power which a generating set is capable of deliveringcontinuouslywhilst supplying a constant electrical load.Average load can be 100%. The generator must not be overloaded. Standby Power The maxpower available during a variable electrical power sequence,under the stated operating conditions, for which a generatingset is capable of delivering in the event of a utilitypower outage orunder test conditions for up to 200 hrs of operation per year underaverage of 70%load.Overloading isn’t permissible. Prime Power The maximum power which a generating set is capable of deliveringcontinuouslywhilst supplying a variable electrical load.Average load should be 70%. The generator can be overloaded 10% for1 hour per 12 hrs.
