Sliding door 3100

steelstainless steelsecurity

The Model 3100 service door is an excellent choice where high usage or easy operation is a must. It offers options that will satisfy almost any non-labeled sliding door requirement. Applications include warehouse doors, doors with high wind load, or wall openings that provide access to oversize manufacturing equipment. Available in single slide or center parting configurations. FEATURES CONSTRUCTION Door Panel – The modular panel is constructed with Kraft honeycomb core securely bonded to 18 gauge cold rolled face sheets and utilizes 18 gauge interior channels. Panels over 52” wide are connected with surface applied splice plates for easy installation. Door Finish – The door is shipped prime painted with a high quality rust resistant paint. Optional finishes include galvanized with prime paint or stainless steel. Capping Channels – Panels are assembled with 14 gauge capping channel and 10 gauge bottom guide roller channel. Pull handles – Flush pull handles on both sides permits easy manual operation. Track Hardware – Doors are equipped with the patented Easy Roll hardware system, which offers the lowest friction of any service door. The system is consists of 2” x 2” x 3/8” angle track, heavy-duty hangers with 3/8” x 3-1/2” hanger frames, 5-1/4” diameter wheels and precision ball bearings. Optional Track Hood – Is 18 gauge carbon steel prime painted with a high quality rust resistant paint available in stainless steel. Optional Dual Durometer Blade Weatherstripping – provides an excellent seal. Optional Mortised Lock – Offers a finished look with casual security and allows the door to unlock from either side.
